WING3020-ZKIT

Rollkit drive for double-leaf gate, set with photocells

Mark: Rollkit, Max. wing length: 3m, Recommended weight of the wing: 120kg, Frequency (MHz): 433, End point: Need end points for open and close position, Code type: Fix, Parts of the set: WING3020L-1x, WING3020R-1x, CUW2-1x, PHOENIX2-1x, FT15-1pár, Drive slowdown: Drive decelerate before endpoint, Motor power supply: AC 230V, Performance: 330W, Force: 1600N, Speed: 90° - 17s, Power supply: AC 230V, Type: Threaded, Controller: CUW-2, Capacitor: 8uF

€330,00
without VAT
€399,30
with VAT
PCS
Stock availability
SK Krompachy - centrálny sklad > 10
SK Banská Bystrica 0
SK Bratislava R1 0

Contact

For more information, contact our sales representative:

lubomir.petruska@umakov.sk
+421915093533 +393483490444
Description Parameters Download Assembly parts Catalog sheet Mandatory assortment Recommended products Alternative products In sets

Parameters

Mark
Information about producer of product
Rollkit
Max. wing length
Maximum wing length for the given drive
3m
Recommended weight of the wing
KRÍDLO
120kg
Drive slowdown
Drive decelerate before endpoint
Type
TYP
Threaded
Frequency (MHz)
Určuje frekvenciu ovládača a riadiacej elektroniky.
433
End point
Need end points for open and close position
Code type
KÓD
Fix
Parts of the set
null
Power supply
Drive-unit power supply
AC 230V
Motor power supply
Drive-unit power supply
AC 230V
Performance
330W
Force
1600N
Speed
90° - 17s
Controller
CUW-2
Capacitor
8uF

Download

PDF
Manual – short version
JPG
Spare parts catalog

Assembly parts

ROLLKIT motor pre krídlovú bránu ľavý ROLLKIT motor pre krídlovú bránu ľavý

ROLLKIT motor for swing gate left WING3020-L

1 pcs
Mark
Rollkit
Max. wing length
3m
Recommended weight of the wing
120kg
ROLLKIT motor pre krídlovú bránu pravý ROLLKIT motor pre krídlovú bránu pravý

ROLLKIT motor for swing gate right WING3020-R

1 pcs
Mark
Rollkit
Max. wing length
3m
Recommended weight of the wing
120kg
ROLLKIT elektronika pre WING 3020

Rollkit control unit 230V CA310

1 pcs
Mark
Rollkit
Drive slowdown
Drive decelerate before endpoint
Motor power supply
AC 230V
Diaľkový ovládač 433Mhz

Remote controller T/4EGR

1 pcs
Mark
Rollkit
Frequency (MHz)
433
Number of channels
4
